Pipeline pump is a centrifugal pump whose inlet and outlet are on the same straight line and have the same caliber. It can be installed at any position of the pipeline in series like a section of pipeline, so it is called pipeline pump. It is defined and named according to the special appearance of the pump. If it is named according to the principle, the pipeline pump is a centrifugal pump with special structure, while the ordinary centrifugal pump may be horizontal end suction type or vertical multistage centrifugal type.
Product Description
Booster pump, just as its name implies, is a pump used for boosting pressure. Its main uses include water heater boosting, low water pressure in high buildings, sauna bath, bathing and other pressurizing uses, insufficient water pressure at the top of apartments, automatic solar boosting and so on.
Pipeline pump is a centrifugal pump whose inlet and outlet are on the same straight line and have the same caliber. It can be installed at any position of the pipeline in series like a section of pipeline, so it is called pipeline pump. It is defined and named according to the special appearance of the pump. If it is named according to the principle, the pipeline pump is a centrifugal pump with special structure, while the ordinary centrifugal pump may be horizontal end suction type or vertical multistage centrifugal type.
Product parameter
Product model | LRS-100 | LRS-150 | LRS-280 |
Voltage | 220V/50HZ | 220V/50HZ | 220V/50HZ |
Power | 100W | 150W | 280W |
Temperature resistance | 0-65℃ | 0-65℃ | 0-100℃ |
Power cord length | About 1 meter | About 1 meter | About 1 meter |
Max Head | 8M | 15M | 20M |
Flow | 10L/min | 15L/min | 18L/min |
Weight | 3kg | 4kg | 5kg |
Size | 17*17*9cm | 20.5*20*10cm | 23*20*12.5 |
